Maxsure Tec
Features
High brightness LED display
Automatic brightness adjustment
Local & remote (optional) programming
Long life cycle
Durable powder coated enclosure resists elements
Lockable & secure enclosure
Numerous sizes
Basic Specifications
LED sign
Display size: 800*800mm or 600*600mm optional
Display type: 3 digital display
Voltage: DC12V
Radar
Frequency: 24.15GHz
Antenna angle: 10°×14°
Numbers of lanes covered: 2~4
Speed range: (5~400) km/h
Speed accuracy: (-4~0) km/h
Detection range: 10~200m
Vehicle flow information: Support
Update cycle: 16ms
Direction: Approaching, receding and both
Remote software update: Support
Interface: Full duplex RS232 or half duplex RS485
Power: (8.5~26) VDC
Operating power: <2w
Operating temp: -40ºC~85ºC
Operating humidity: 5%~95%
IP grade: IP67
Size: 116 X 90 X 40MM
Power
100AH battery 100W solar panel optional
Control
Both 4G remote control and pc control on site control
Mounting frame
Frame material: MIG-welded, 30mm square steel tubing, can be customized
Finishing: powder coated and oven baked
Application scenario
Temporary road ontrol
Emergency traffic response
Road maintenance and repair
Temporary traffic control
Outdoor traffic safety equipment and outdoor engineering equipment products are important equipment to ensure people's safety during outdoor activities. These devices can not only improve people's safety in outdoor activities, but also improve the efficiency and quality of engineering construction. The following are our technical and service advantages.
Technical advantages:
1. Modern outdoor traffic safety equipment and engineering equipment adopt high-precision positioning technology, which can accurately locate the positions of personnel and equipment, improve safety and work efficiency.
2. These devices are equipped with intelligent monitoring systems, which can monitor the operating status and working environment of the devices in real time, detect problems in a timely manner, and take measures to ensure safety and stability.
3. These devices are made of high-strength materials, which have good wear resistance and corrosion resistance, and can be used for a long time in harsh outdoor environments.
4. These devices adopt high-efficiency and energy-saving technology, which can reduce energy consumption and operating costs, improve the service life and economic benefits of the equipment.
Service advantages:
1. providing customized services, designing and producing products that meet customer needs and requirements.
2. providing comprehensive after-sales service, including installation and debugging, training services, maintenance, etc., to ensure that customers can use the equipment normally and maintain its good condition.
3. Providing technical support, including equipment operation guidance, troubleshooting, maintenance and other services, to help customers solve problems during equipment use.
4. providing quickly respond to customer needs, promptly address customer issues and feedback, and ensure that customers can obtain a satisfactory service experience.
Our products have advanced technological advantages and high-quality service advantages, which can provide safe and efficient guarantees for outdoor activities and engineering construction. With the continuous development and progress of technology, these devices will continuously improve their performance and service level, bringing more convenience and safety assurance to people's outdoor life and engineering construction.
